SPECS
CORE SPECIFICATIONS
FREQUENCY RESPONSE
20Hz ~ 20kHz
SAMPLE RATE / BIT DEPTH
48kHz / 24-bit
LATENCY
< 3ms
DYNAMIC RANGE
103.7 dB
CONTROLS AND CONNECTIVITY
TOP PANEL CONTROLS & DISPLAYS
Power button
LED indicator
REAR PANEL CONTROLS
USB Type-C charging port
WIRELESS CONNECTIVITY
Positive Grid proprietary wireless audio (2.4GHz)
TRANSMISSION RANGE
Up to 70 feet line-of-sight (21 meters)
COMPATIBLE CHANNELS
4 channels
PHYSICAL UNIT
DIMENSIONS
Spark LINK LXR TX :
L x H x W: 98.99mm x 27.6mm x 25.4mm (3.9in x 1.1in x 1in)
Spark LINK LXR RX :
L x H x W: 93.96mm x 27.6mm x 25.4mm (3.7in x 1.1in x 1in)
WEIGHT
Spark LINK XLR TX: 55.9 g (0.12lbs)
Spark LINK XLR RX: 50.7 g (0.11lbs)
INCLUDED IN THE BOX
BOX CONTENTS
Spark LINK LXR TX (Transmitter)
Spark LINK LXR RX (Receiver)
USB C to C Cable (1.5 meters)
Quick Start Guide
Safety Instructions
POWER
MAIN INPUT POWER
DC 5V/1A (USB)
BATTERY TYPE
500mAh rechargeable lithium-ion battery
PLAY TIME
Up to 7 hours of continuous use
CHARGING TIME
2 hours
